Description
GROWATT MID 17KTL3-X inverter, a high-performance inverter designed to elevate your renewable energy system to new heights. With a maximum string input current of 16A, this inverter ensures efficient and reliable power conversion, allowing for seamless integration of solar energy into your home or business.
Featuring advanced functionalities, this inverter offers superior protection for your system. It boasts a Type II Surge Protection Device (SPD) on both DC and AC sides, safeguarding your valuable equipment against voltage spikes and transient overvoltages, thereby providing peace of mind and enhancing system longevity.
The I/V curve scanning capability of this inverter enables precise tracking and optimization of solar panel performance, ensuring maximum energy harvest under varying weather conditions. By continuously monitoring the current-voltage relationship, the inverter intelligently adjusts its output to deliver the most efficient power conversion possible.
Furthermore, to enhance system reliability, our advanced inverter incorporates a smart string monitoring function. This cutting-edge technology continuously monitors the performance of individual solar strings, allowing for early detection of any potential issues or malfunctions. By taking this proactive approach, the inverter ensures that the entire system operates at peak efficiency, minimizing any potential downtime.
To further cater to your specific needs, this inverter also offers an optional Arc Fault Circuit Interrupter (AFCI) feature. The AFCI technology detects and mitigates the risk of electrical arcing, providing an additional layer of safety for your solar installation.
Engineered with state-of-the-art technology and built to the highest quality standards, our inverter is the perfect choice for your e-commerce store. It combines unparalleled performance, robust protection, and intelligent monitoring capabilities to maximize the productivity and longevity of your solar energy system. Experience the power of innovation and take control of your renewable energy future with our exceptional inverter.
GROWATT MID 17KTL3-X
The GROWATT MID 17KTL3-X inverter offers affordable pricing and high quality. It is certified for the global market and is often used in pro-consumer installations. Growatt inverters can be purchased with self-consumption monitoring devices called Smart Energy Managers. It can also provide flexible CTs for various system sizes with high control accuracy. This has the failsafe function to ensure system safety and reliability. It also has a 0 export limitation function.
Three-phase inverter designed for residential and commercial applications. Available capacities: 15kW, 17kW, 20kW, 25kW, 30kW, 33kW, 36kW, 40kW, 50kW. The inverter is also equipped with a range of advanced features that make it easy to install and use. It has a user-friendly interface that allows homeowners and installers to monitor system performance and adjust settings as needed. The inverter is also compatible with a range of monitoring systems, including WiFi, Ethernet, and RS485.
GENERAL INFORMATION
- Photovoltaic inverters have two MPPT inputs
- Equipped with lightning protection – Type II AC/DC
- Inverters have built-in protections that protect against faults caused by material wear. Additionally, they ensure safety against the phenomenon of electrical arcing (AFCI)
- Inverters are rated IP65, so they can be installed outdoors
- Qualified installers can remotely control the operating parameters of photovoltaic panels and the electrical grid
- Management of the photovoltaic installation is possible thanks to the fully interpolated ShinePhone application
- Touch screen, with which you can easily and quickly read the inverter’s operating parameters. Guaranteed durability even after a minimum of 20,000 clicks
- Lightweight, durable, and flame-retardant inverter thanks to a high-strength polycarbonate cover
Basic specifications of the GROWATT MID 17KTL3-X inverter:
- Maximum recommended PV power (per STC module) [W]: 25500
- Maximum DC voltage [V]: 1100
- Nominal voltage [V]: 580
- Rated AC power [W]: 17000
- Maximum output current [A]: 27.4
- Dimensions (W / H / D) [mm]: 525 / 395 / 222
- Weight [kg]: 23
- Maximum efficiency [%]: 98.75
- Protection rating: IP65
- Interfaces: RS232 / RS485 / CAN / USB
- Cooling: Smart air cooling
- Topology: Transformerless
